Rotary Tower Automatic Pallet Wrapper Flex RTA Rotary Tower Automatic

The RTA semi-automatic stretch wrapping system is the fastest way to boost your end-of-line packaging efficiency by eliminating the need for operators to manually attach the film tail to the load, then cut and secure the film tail at the end of the cycle. The RTA stretch wrapper automatically performs these functions so your operators simply place the load, pull a handing lanyard to start the cycle, and attend to other duties. When they return the load is securely wrapped and ready to be removed.

includes an automatic film tail with attach, cut, and press capabilities.  With no maximum load weight capacity, your product needs are easily met.  there is a floor mounted control panel for flexibility along with the structural steel construction for durability.

A start cycle with hanging lanyard comes standard on the Flex RTA Series.  A tower mounted obstacle sensing system is available for a more controlled, safe environment.  And for precision, there is a precision ring bearing drive system available.

Request more info about this product
  • Features & Specs

    Performance Features:

    • 7" IntelleVue color HD touch screen HMI
    • 16 RPM Variable Speed Tower
    • Automatic Film Tail Attach/Cut/Press
    • Start Cycle With Hanging Lanyard
    • No Maximum Load Weight Capacity
    • Precision Ring Bearing Drive System
    • AC/VFD Motors for Reduced Maintenance
    • Structural Steel Construction for Durability
    • Heavy Duty Chain & Sprocket Drive
    • Tower Mounted Obstacle Sensing System
    PRODUCTION SPEED Up to 40-50 loads per hour
    MAXIMUM LOAD SIZE 48"W x 48"L x 80"H (68" Diagonal)
    InstaThread FILM DELIVERY SYSTEM Film roll: 20" Standard - 30" Optional - 10" Diameter
    Standard prestretch ratio: 260% (higher available)
    Wrap to within 3" of floor
    Automatic load height sensing photoeye
    Automatic film force-to-load control
    SHIPPING WEIGHT 2,500+ lbs. (Varies with options)
    WARRANTY 4 Years on ALL major components
    5 Years on structural frame
    UTILITIES 115/1/60, 20 Amp electrical service
    80 PSI @ CFM compressed air
